2ZS-430
Keywords：hose
Category：
TRANSPLANTER
Hotline:
2ZS-430
Detail
High-accuracy planting
Convenient and efficient rice transplanter
High output and low fuel consumption!
| Item | Unit | Specification | |
| Model | / | 2ZS-430 | |
| Structure Form | / | Two Wheels Three Floating Plates Type | |
| Working Dimension | mm | 2140*1630*910 | |
| Structure Weight | kg | 163 | |
| Size | Transplanting width Row to Row | / | 300mm |
| Transplanting hill to hill | / | 10-25cm | |
| Type of Wheel | / | Rubber/Aluminum coated steel | |
| Tire Diameter | mm | 660mm | |
| Engine | Engine Model | / | JL175 |
| Maximum Output/Speed kW | / | 2.60kW@3600rpm | |
| Engine Type | / | Air-cooled,4 Cycle,OHV,Gasoline Engine | |
| Fuel | lead-free Gasoline | ||
| Total Displacement | / | 170CC | |
| Engine crank case | r/min | 0.6L | |
| Capability | Starting Method | hm2/h | Recoil Start |
| Fuel tank capacity | ltr/hm2 | 04LTR | |
| Working Speed | m/s | 0.34-0.80 | |
| Planting Density | Transplanting depth control | / | Hydraulic |
| Planting Density | Line Distance of Transplanting Seeding |
mm | 300 |
| Transplanting speed | / | 0.34 to 0.80 m/sec | |
| Traveling Speed Forward | / | ||
| Transverse Taking Seedling Times |
/ | 14/16/18/20/26 | |
| Transplanting pitch adjustments |
/ | 04 Positions | |
| Planting arm case | / | 0.02L | |
| Gearshift Method | / | Gear Shifting | |
| Type | / | Rubber Wheel Claw Type | |
| Transplanting depth adjustments | mm | 6 Positions | |
| Number of transplanting rows at once | / | 4 | |
| Work-part Structural Type | / | Crank Rocker Type | |
